Split hydraulic punching machine
  • Split hydraulic punching machineSplit hydraulic punching machine
  • Split hydraulic punching machineSplit hydraulic punching machine
  • Split hydraulic punching machineSplit hydraulic punching machine
  • Split hydraulic punching machineSplit hydraulic punching machine
  • Split hydraulic punching machineSplit hydraulic punching machine
  • Split hydraulic punching machineSplit hydraulic punching machine
  • Split hydraulic punching machineSplit hydraulic punching machine

Split hydraulic punching machine

As the professional manufacture, we would like to provide you Battery Hydraulic Crimping Tool .EMEADS is capable to provide the Battery Hydraulic Crimping Tool with high quality and competitive price. All of our products are up to the international standard(ISO9001). We have received a good reputation both at home and abroad. Our products have been well sold to more than 30 countries,such as Japan, America, Australia,Italy, and the middle east, etc. We look forward to becoming your long-term partner in China.

Model:CH-80/100/200

Send Inquiry

Product Description

CH-80/100/200  (Common/Punch H steel) split hydraulic punching machine,iron plateangle iron Channel H-beam;Tips:Our ch-80 / 100 / 200 punching machine has two types: ordinary type and H steel type ,Common punching: iron plate, angle iron and channel steel, Channel steel mainly punching: iron plate, angle iron, channel steel, H-beam;*The above machines can only punch the wide side of channel steel and H-beam, not narrow side.


Product Parameters

Model Punch Range Mold Configure Net/Gross Weigh(kg)
Iron Plate Thickness Angle Steel Channel H Steel
CH-80 Common ≤16mm 6-12# 8-15# X Φ16/Φ18/Φ22/Φ25 74/77.6
CH-80 Punch H steel ≤16mm 6-12# 8-15# 8-15# Φ16/Φ18/Φ22/Φ25 81/84.6
CH-100 Common ≤20mm 8-15# 10-15# X Φ22/Φ25/Φ28/Φ32 119/124.5
CH-100 Punch H steel ≤20mm 8-15# 10-15# 10-15# Φ22/Φ25/Φ28/Φ32 130/135.5
CH-200 Common ≤30mm 8-15# 10-20# X Φ22/Φ25/Φ28/Φ32 /
CH-200Punch H steel ≤30mm 8-15# 10-20# 10-20# Φ22/Φ25/Φ28/Φ32 /
*The above machines can only punch the wide side of channel steel and H-beam, not narrow side
Tips Our ch-80 / 100 / 200 punching machine has two types: ordinary type and H steel typeCommon punching: iron plate, angle iron and channel steelChannel steel mainly punching: iron plate, angle iron, channel steel, H-beam

Product display
