FPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack
  • FPY Thin-wall hydraulic cylinder jackFPY Thin-wall hydraulic cylinder jack

FPY Thin-wall hydraulic cylinder jack

As a professional manufacturer, EMEADS has the ability to provide hydraulic cylinder jack with high quality and competitive price. All of our products comply with international standards (ISO9001). We have gained a good reputation at home and abroad. Our products have been sold well in more than 30 countries including Japan, the United States, Australia, Italy, and the Middle East. We look forward to becoming your long-term partner in China.

Model:FPY-5/10/20/30/50/100/150/200

Send Inquiry

Product Description

Model:FPY-5/10/20/30/50/100/150/200;Compact  Compact,Strong Jacking Force;For proper operation, all cylinders need to be connected to a solid lifting surface,If the thin cylinder is used in the sand, soil or loose surface, the cylinder will be damaged.Function:Light weight compact design for narrow workspace,Paint surface enhances corrosion resistance,Dust ring reduces pollution and prolongs service life of cylinder,It is portable and easy to carry. There are two holes in the cylinder plane for fixed use.


Product Parameters

Model Tonnage(T) Self Height(mm) Stroke(mm) Externaldiameter(mm) Internaldiameter(mm) Weight(kg) EffectiveArea(cm) Collocation
FPY-5 5 42 8 64X48 30 0.7 9.61 CP-180
FPY-10 10 52 12 83X65 38 1.6 15.89 CP-180
FPY-20 20 58 14 99X80 50 2.75 33.16 CP-180
FPY-30 30 64 14 118X100 65 5 50.24 CP-700
FPY-50 50 72 18 148X128 80 8.5 78.5 CP-700
FPY-100 100 88 22 188X165 110 19 143.06 CP-700
FPY-150 150 100 23 228X200 135 23 226.8 CP-700-2
FPY-200 200 106 23 268X236 160 33 CP-700-2
Function Light weight compact design for narrow workspace.Paint surface enhances corrosion resistance.Dust ring reduces pollution and prolongs service life of cylinder.It is portable and easy to carry. There are two holes in the cylinder plane for fixed use.

Product display
